Trek Marlin+ 8 E-Bike For Sale Online

Trek Marlin+ 8 is an electric mountain bike that’s ready to up your game on the trail. Its Bosch Active Line Plus motor gives you just the boost you need for getting up steep climbs and riding farther, and doesn’t break the bank, and a 120mm suspension fork keeps handling smooth through the rough stuff. Upgraded components, like wide tubeless-ready wheels and tires and a 12-speed Shimano drivetrain make this a trail-savvy ride that’s ready to go anywhere.

Its AUTO mode adaptive motor support recognizes speed reductions and adjusts assistance automatically
The 120mm suspension keeps your ride feeling smooth through bumps, roots, and rough stuff
Marlin+ is easy to use with simple controls and intuitive support, so you can focus on the ride ahead, not complicated remotes
Trail-savvy geometry keeps handling easy and confident from singletrack to city streets
Tons of rack and fender mounts let you customize your ride for the trail or taking on daily commutes

Features at a Glance

Weight: 21.5 kg
Frame: Aluminum
Suspension: Hardtail, 120mm
Fork: RockShox Recon Silver RL
Wheels: 27.5″ / 29″ Aluminum
Groupset: Deore, FSA
Drivetrain: 1 × 12
Motor: Bosch 6000W 50Nm mid-drive
Battery: Bosch 400Wh
Brakes: Hydraulic Disc

Specifications Of Trek Marlin+ 8 – 2024

Build

Frame	Size: XS, Alpha Gold Aluminum, curved top tube, tapered head tube, internal routing, rack, fender, and kickstand mount, UDH, Boost148, 12mm thru axle; Size: S, M, L, XL, Alpha Gold Aluminum, tapered head tube, internal routing, rack, fender, and kickstand mount, UDH, Boost148, 12mm thru axle Hanger Standard: UDH Tire Clearance: 2.6″
Fork	Size: XS, RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 46mm offset, Boost110, 15mm Maxle Stealth, 100mm travel; Size: S, RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 46mm offset, Boost110, 15mm Maxle Stealth, 120mm travel; Size: M, L, XL, RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 42mm offset, Boost110, 15mm Maxle Stealth, 120mm travel Travel: 120mm Spring Type: Air
Headset	Semi-integrated, sealed cartridge bearing, alloy cups, 1-1/8” top, 1.5” bottom
Stem	Size: XS, S, Bontrager Comp, 31.8mm, 7 degree, 35mm length; Size: M, L, Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 50mm length; Size: XL, Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 60mm length
Handlebar	Size: XS, S, Bontrager alloy, 31.8mm, 15mm rise, 720mm width; Size: M, L, XL, Bontrager alloy, 31.8mm, 15mm rise, 750mm width
Saddle	Size: XS, S, M, L, XL, Bontrager Verse P3, chromoly rails; Size: XS, S, M, L, XL, Bontrager Arvada, hollow chromoly rails, 138mm width
Seatpost	Size: XS, S, TranzX JD-YSP18, 100mm travel, internal routing, 31.6mm, 361mm length; Size: M, L, XL, TranzX JD-YSP18, 150mm travel, internal routing, 31.6mm, 470mm length Type: Dropper
Pedals	VP-536 nylon platform
Grips	Bontrager XR Trail Comp, nylon lock-on

Groupset

Rear Derailleur	Shimano Deore M6100, long cage
Crank	FSA CK-220, 165mm length
Shifters	Shimano Deore M6100, 12 speed
Cassette	Shimano Deore M6100, 10-51, 12 speed
Chain	Shimano Deore M6100, 12 speed
Brakes	Shimano 4-piston hydraulic disc, MT4100 lever, MT420 caliper Type: Hydraulic Disc

Wheels

Rims	Size: XS, S, M, L, XL, Bontrager Line TLR 30, Tubeless Ready, 28-hole, Presta valve; Size: XS, S, M, L, XL, Bontrager Line TLR 30, Tubeless Ready, 32-hole, Presta valve
Front Hub	Shimano TC500 alloy, centerlock, 110x15mm thru axle
Rear Hub	Shimano TC500 alloy, centerlock, 148x12mm thru axle
Tires	Size: XS, S, Bontrager Gunnison Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 27.5×2.60”; Size: M, L, XL, Bontrager Gunnison Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29×2.60”
Disc Rotors	Shimano RT64, centerlock, 203mm
